156 Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide
4 Commands Quick Reference
:SBUS<n>:SENT:TRIGger
:SLOW:DATA <data>
(see page 924)
:SBUS<n>:SENT:TRIGger
:SLOW:DATA? (see
page 924)
<data> ::= when ILENgth = SHORt,
from -1 (don't care) to 65535, in
NR1 format.
<data> ::= when ILENgth = LONG,
from -1 (don't care) to 4095, in
NR1 format.
:SBUS<n>:SENT:TRIGger
:SLOW:ID <id> (see
page 926)
:SBUS<n>:SENT:TRIGger
:SLOW:ID? (see
page 926)
<id> ::= when ILENgth = SHORt,
from -1 (don't care) to 15, in
NR1 format.
<id> ::= when ILENgth = LONG,
from -1 (don't care) to 255, in
NR1 format.
:SBUS<n>:SENT:TRIGger
:SLOW:ILENgth
<length> (see
page 928)
:SBUS<n>:SENT:TRIGger
:SLOW:ILENgth? (see
page 928)
<length> ::= {SHORt | LONG}
:SBUS<n>:SENT:TRIGger
:TOLerance <percent>
(see page 929)
:SBUS<n>:SENT:TRIGger
:TOLerance? (see
page 929)
<percent> ::= from 1-18, in NR1
format.
Table 35 :SBUS<n>:SENT Commands Summary (continued)
Command Query Options and Query Returns
Table 36 :SBUS<n>:SPI Commands Summary
Command Query Options and Query Returns
:SBUS<n>:SPI:BITorder
<order> (see page 932)
:SBUS<n>:SPI:BITorder
? (see page 932)
<order> ::= {LSBFirst | MSBFirst}
:SBUS<n>:SPI:CLOCk:SL
OPe <slope> (see
page 933)
:SBUS<n>:SPI:CLOCk:SL
OPe? (see page 933)
<slope> ::= {NEGative | POSitive}
:SBUS<n>:SPI:CLOCk:TI
Meout <time_value>
(see page 934)
:SBUS<n>:SPI:CLOCk:TI
Meout? (see page 934)
<time_value> ::= time in seconds
in NR3 format
:SBUS<n>:SPI:FRAMing
<value> (see page 935)
:SBUS<n>:SPI:FRAMing?
(see page 935)
<value> ::= {CHIPselect |
{NCHipselect | NOTC} | TIMeout}
:SBUS<n>:SPI:SOURce:C
LOCk <source> (see
page 936)
:SBUS<n>:SPI:SOURce:C
LOCk? (see page 936)
<value> ::= {CHANnel<n> |
EXTernal} for the DSO models
<value> ::= {CHANnel<n> |
DIGital<d>} for the MSO models
<n> ::= 1 to (# analog channels)
in NR1 format
<d> ::= 0 to (# digital channels
- 1) in NR1 format
