Keysight Technologies InfiniiVision MSO-X 4022A

Commands Quick Reference 4
Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide 157
:SBUS<n>:SPI:SOURce:F
RAMe <source> (see
page 937)
:SBUS<n>:SPI:SOURce:F
RAMe? (see page 937)
<value> ::= {CHANnel<n> |
EXTernal} for the DSO models
<value> ::= {CHANnel<n> |
DIGital<d>} for the MSO models
<n> ::= 1 to (# analog channels)
in NR1 format
<d> ::= 0 to (# digital channels
- 1) in NR1 format
:SBUS<n>:SPI:SOURce:M
ISO <source> (see
page 938)
:SBUS<n>:SPI:SOURce:M
ISO? (see page 938)
<value> ::= {CHANnel<n> |
EXTernal} for the DSO models
<value> ::= {CHANnel<n> |
DIGital<d>} for the MSO models
<n> ::= 1 to (# analog channels)
in NR1 format
<d> ::= 0 to (# digital channels
- 1) in NR1 format
:SBUS<n>:SPI:SOURce:M
OSI <source> (see
page 939)
:SBUS<n>:SPI:SOURce:M
OSI? (see page 939)
<value> ::= {CHANnel<n> |
EXTernal} for the DSO models
<value> ::= {CHANnel<n> |
DIGital<d>} for the MSO models
<n> ::= 1 to (# analog channels)
in NR1 format
<d> ::= 0 to (# digital channels
- 1) in NR1 format
:SBUS<n>:SPI:TRIGger:
PATTern:MISO:DATA
<string> (see
page 940)
:SBUS<n>:SPI:TRIGger:
PATTern:MISO:DATA?
(see page 940)
<string> ::= "nn...n" where n ::=
{0 | 1 | X | $}
<string ::= "0xnn...n" where n
::= {0,..,9 | A,..,F | X | $}
:SBUS<n>:SPI:TRIGger:
PATTern:MISO:WIDTh
<width> (see page 941)
:SBUS<n>:SPI:TRIGger:
PATTern:MISO:WIDTh?
(see page 941)
<width> ::= integer from 4 to 64
in NR1 format
:SBUS<n>:SPI:TRIGger:
PATTern:MOSI:DATA
<string> (see
page 942)
:SBUS<n>:SPI:TRIGger:
PATTern:MOSI:DATA?
(see page 942)
<string> ::= "nn...n" where n ::=
{0 | 1 | X | $}
<string ::= "0xnn...n" where n
::= {0,..,9 | A,..,F | X | $}
:SBUS<n>:SPI:TRIGger:
PATTern:MOSI:WIDTh
<width> (see page 943)
:SBUS<n>:SPI:TRIGger:
PATTern:MOSI:WIDTh?
(see page 943)
<width> ::= integer from 4 to 64
in NR1 format
Table 36 :SBUS<n>:SPI Commands Summary (continued)
Command Query Options and Query Returns
