Keysight Technologies InfiniiVision MSO-X 4022A

Commands Quick Reference 4
Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide 159
:SBUS<n>:UART:POLarit
y <polarity> (see
page 958)
:SBUS<n>:UART:POLarit
y? (see page 958)
<polarity> ::= {HIGH | LOW}
:SBUS<n>:UART:SOURce:
RX <source> (see
page 959)
:SBUS<n>:UART:SOURce:
RX? (see page 959)
<source> ::= {CHANnel<n> |
EXTernal} for DSO models
<source> ::= {CHANnel<n> |
DIGital<d>} for MSO models
<n> ::= 1 to (# analog channels)
in NR1 format
<d> ::= 0 to (# digital channels
- 1) in NR1 format
:SBUS<n>:UART:SOURce:
TX <source> (see
page 960)
:SBUS<n>:UART:SOURce:
TX? (see page 960)
<source> ::= {CHANnel<n> |
EXTernal} for DSO models
<source> ::= {CHANnel<n> |
DIGital<d>} for MSO models
<n> ::= 1 to (# analog channels)
in NR1 format
<d> ::= 0 to (# digital channels
- 1) in NR1 format
:SBUS<n>:UART:TRIGger
:BASE <base> (see
page 961)
:SBUS<n>:UART:TRIGger
:BASE? (see page 961)
<base> ::= {ASCii | HEX}
:SBUS<n>:UART:TRIGger
:BURSt <value> (see
page 962)
:SBUS<n>:UART:TRIGger
:BURSt? (see page 962)
<value> ::= {OFF | 1 to 4096 in
NR1 format}
:SBUS<n>:UART:TRIGger
:DATA <value> (see
page 963)
:SBUS<n>:UART:TRIGger
:DATA? (see page 963)
<value> ::= 8-bit integer from
0-255 (0x00-0xff) in decimal,
<hexadecimal>, <binary>, or
<quoted_string> format
<hexadecimal> ::= #Hnn where n
::= {0,..,9 | A,..,F} for
hexadecimal
<binary> ::= #Bnn...n where n ::=
{0 | 1} for binary
<quoted_string> ::= any of the
128 valid 7-bit ASCII characters
(or standard abbreviations)
:SBUS<n>:UART:TRIGger
:IDLE <time_value>
(see page 964)
:SBUS<n>:UART:TRIGger
:IDLE? (see page 964)
<time_value> ::= time from 1 us
to 10 s in NR3 format
:SBUS<n>:UART:TRIGger
:QUALifier <value>
(see page 965)
:SBUS<n>:UART:TRIGger
:QUALifier? (see
page 965)
<value> ::= {EQUal | NOTequal |
GREaterthan | LESSthan}
Table 37 :SBUS<n>:UART Commands Summary (continued)
Command Query Options and Query Returns
