160 Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide
4 Commands Quick Reference
:SBUS<n>:UART:TRIGger
:TYPE <value> (see
page 966)
:SBUS<n>:UART:TRIGger
:TYPE? (see page 966)
<value> ::= {RSTArt | RSTOp |
RDATa | RD1 | RD0 | RDX |
PARityerror | TSTArt | TSTOp |
TDATa | TD1 | TD0 | TDX}
:SBUS<n>:UART:WIDTh
<width> (see page 967)
:SBUS<n>:UART:WIDTh?
(see page 967)
<width> ::= {5 | 6 | 7 | 8 | 9}
Table 37 :SBUS<n>:UART Commands Summary (continued)
Command Query Options and Query Returns
Table 38 :SBUS<n>:USB Commands Summary
Command Query Options and Query Returns
:SBUS<n>:USB:BASE
<base> (see page 971)
:SBUS<n>:USB:BASE?
(see page 971)
<base> ::= {ASCii | BINary |
DECimal | HEX}
:SBUS<n>:USB:SOURce:D
MINus <source> (see
page 972)
:SBUS<n>:USB:SOURce:D
MINus? (see page 972)
<source> ::= {CHANnel<n>} for DSO
models
<source> ::= {CHANnel<n> |
DIGital<d>} for MSO models
<n> ::= 1 to (# analog channels)
in NR1 format
<d> ::= 0 to (# digital channels
- 1) in NR1 format
:SBUS<n>:USB:SOURce:D
PLus <source> (see
page 973)
:SBUS<n>:USB:SOURce:D
PLus? (see page 973)
<source> ::= {CHANnel<n>} for DSO
models
<source> ::= {CHANnel<n> |
DIGital<d>} for MSO models
<n> ::= 1 to (# analog channels)
in NR1 format
<d> ::= 0 to (# digital channels
- 1) in NR1 format
:SBUS<n>:USB:SOURce:D
IFFerential <source>
(see page 974)
:SBUS<n>:USB:SOURce:D
IFFerential? (see
page 974)
<source> ::= {CHANnel<n>}
<n> ::= 1 to (# analog channels)
in NR1 format
:SBUS<n>:USB:SPEed
<speed> (see page 975)
:SBUS<n>:USB:SPEed?
(see page 975)
<speed> ::= {LOW | FULL | HIGH}
:SBUS<n>:USB:TRIGger
<condition> (see
page 976)
:SBUS<n>:USB:TRIGger?
(see page 976)
<condition> ::= {SOP | EOP |
ENTersuspend | EXITsuspend |
RESet | TOKen | DATA | HANDshake
| SPECial | ALLerrors | PIDerror
| CRC5error | CRC16error |
GLITcherror | STUFFerror |
SE1error}
