252 Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide
6 Root (:) Commands
Query Syntax :OVLenable?
The :OVLenable query returns the current enable mask value contained in the
Overload Event Enable Register.
Return Format
<enable_mask><NL>
<enable_mask> ::= integer in NR1 format.
See Also • "Introduction to Root (:) Commands" on page 226
• ":CHANnel<n>:PROTection" on page 319
• ":OPEE (Operation Status Enable Register)" on page 245
• ":OPERegister:CONDition (Operation Status Condition Register)" on page 247
• ":OPERegister[:EVENt] (Operation Status Event Register)" on page 249
• ":OVLRegister (Overload Event Register)" on page 253
• "*STB (Read Status Byte)" on page 218
• "*SRE (Service Request Enable)" on page 216
3 Channel 4 OVL Event when overload occurs on Channel 4 input.
2 Channel 3 OVL Event when overload occurs on Channel 3 input.
1 Channel 2 OVL Event when overload occurs on Channel 2 input.
0 Channel 1 OVL Event when overload occurs on Channel 1 input.
Table 88 Overload Event Enable Register (OVL) (continued)
Bit Description When Set (1 = High = True), Enables:
