Keysight InfiniiVision 4000 X-Series Oscilloscopes
Programmer's Guide
29 :SBUS<n> Commands
Control the modes and parameters for each serial bus decode/trigger type. See:
• "Introduction to :SBUS<n> Commands" on page 755
• "General :SBUS<n> Commands" on page 757
• ":SBUS<n>:A429 Commands" on page 760
• ":SBUS<n>:CAN Commands" on page 777
• ":SBUS<n>:CXPI Commands" on page 807
• ":SBUS<n>:FLEXray Commands" on page 824
• ":SBUS<n>:I2S Commands" on page 843
• ":SBUS<n>:IIC Commands" on page 862
• ":SBUS<n>:LIN Commands" on page 872
• ":SBUS<n>:M1553 Commands" on page 890
• ":SBUS<n>:SENT Commands" on page 897
• ":SBUS<n>:SPI Commands" on page 930
• ":SBUS<n>:UART Commands" on page 946
• ":SBUS<n>:USB Commands" on page 968
Introduction to
:SBUS<n>
Commands
The :SBUS subsystem commands control the serial decode bus viewing, mode,
and other options.
The following serial bus decode/trigger types are available (see ":TRIGger:MODE"
on page 1148).
• CAN (Controller Area Network) triggering— will trigger on CAN version 2.0A and
2.0B signals. Setup consists of connecting the oscilloscope to a CAN signal.
Baud rate, signal source, and signal polarity, and type of data to trigger on can
be specified. You can trigger on CAN data and identifier patterns and you can
set the bit sample point.
• CXPI triggering (with CXPI license) — lets you trigger on CXPI serial data.
NOTE
These commands are only valid on oscilloscope models when a serial decode option has been
licensed.
