[S2]
Storage
location
Name
Number
of words
Description
[D+4]- [D+9]
Latest transfer
success time
6
Year, month, day, hour, minute and second when
the last transfer succeeded
[D+10]- [D
+15]
Latest transfer
failure time
6
Year, month, day, hour, minute and second when
the last transfer failed
[D+16]- [D
+17]
Number of transfer
successes
(Whole)
2 Number of times that transfer succeeded
[D+18]- [D
+19]
Number of transfer
failures (Whole)
2 Number of times that transfer failed
Total number of words 20 -
2
"IDx"
"IDALL"
(Note 1)
[D]
Control relay
(Note
3)
1
FTPc control relay, HTTPc control relay, Mail
transmission control relay
[D+1]
Execution done
code
(Note 4)
1
0: Normal completion. An error code is stored at
abnormal completion.
[D+2]
Transfer done
code
1
FTP/HTTP/SMTP response code
(Note 5)
[D+3]- [D+4]
Number of
successful
executions
(individual)
2 Number of times that transfer succeeded
[D+5]- [D+6]
Number of failed
executions
(individual)
2 Number of times that transfer failed
Total number of words 7 -
3
"LOGx"
"LOGALL
"
(Note 2)
[D]
Control relay
(Note
3)
1
FTPc logging control relay, HTTPc logging
control relay, Mail transmission logging control
relay
[D+1]
Execution done
code
(Note 4)
1
0: Normal completion. An error code is stored at
abnormal completion.
[D+2]
Transfer done
code
1
FTP/HTTP/SMTP response code
(Note 5)
[D+3]- [D+4]
Number of
successful
executions
(individual)
2 Number of times that transfer succeeded
[D+5]- [D+6]
Number of failed
executions
(individual)
2 Number of times that transfer failed
Total number of words 7 -
(Note 1) When "IDALL" is specified, the entire status (20 words) and the status (7 words) for each registered ID
are read.
(Note 2) When "LOGALL" is specified, the entire status (20 words) and the status (7 words) for each registered
LOG are read.
(Note 3) The control relay reads the states of relays for each ID or LOG setting. Refer to "P.17-19".
(Note 4) For details of execution done codes at abnormal completion, refer to "P.17-19".
(Note 5) For details of FTP/HTTP/SMTP response codes, refer to "P.17-20" to "P.17-21".
17.3 ETSTAT (Acquiring Ethernet Unit Information: FTP/HTTP/SMTP)
