Waveform analysis
R&S
®
RTM3000
102User Manual 1335.9090.02 ─ 09
Figure 7-1: Display of horizontal zoom: zoom in bottom window, normal waveform in upper window
1 = Tap to activate zoom settings
2 = Tap to activate normal waveform settings
3 (blue) = Horizontal zoom scale and width of the zoom area
4 (red) = Horizontal zoom position
5 = Acquire mode, can be set in zoom window or in the upper status bar
6 = Horizontal scale and position of the normal waveform
7 = Close zoom window
Zoom
