Remote control commands
R&S
®
RTM3000
468User Manual 1335.9090.02 ─ 09
NEGative
If the modulation is negative, sync pulses are positive.
*RST: NEGative
TRIGger:A:TV:FIELd <Field>
Sets the trigger on the beginning of the video signal fields, or on the beginning of video
signal lines.
Parameters:
<Field> EVEN | ODD | ALL | LINE | ALINe
EVEN | ODD
Triggers only on the field start of even or odd fields. Only availa-
ble for interlaced scanning.
ALL
All fields, triggers on the frame start (progressive scanning) or
any field start (interlaced scanning).
LINE
Triggers on the beginning of a specified line in any field. The line
number is set with TRIGger:A:TV:LINE.
ALINe
Triggers on the beginning of all video signal lines.
*RST:
ALL
TRIGger:A:TV:LINE <Line>
Sets an exact line number if TRIGger:A:TV:FIELd is set to LINE.
Parameters:
<Line> Range: 1 to 525 (NTSC, PAL-M); 625 (PAL, SECAM,
SDTV I-576); 750 (HDTV P720); 1125 (HDTV
I1080, HDTV P1080)
Increment: 1
*RST: 1
17.5.6 Pattern trigger
● Pattern definition................................................................................................... 468
● Time limitation....................................................................................................... 470
17.5.6.1 Pattern definition
TRIGger:A:PATTern:SOURce.......................................................................................... 469
TRIGger:A:PATTern:FUNCtion.........................................................................................469
TRIGger:A:PATTern:CONDition....................................................................................... 469
Trigger
