Remote control commands
R&S
®
RTM3000
472User Manual 1335.9090.02 ─ 09
TRIGger:A:RUNT:POLarity <Polarity>
Indicates the polarity of a the runt to be triggered on.
Parameters:
<Polarity> POSitive | NEGative
*RST: POS
TRIGger:A:RUNT:RANGe <Range>
Sets how the measured pulse width is compared with the given limit(s).
To set the width, use TRIGger:A:RUNT:WIDTh.
To set the range ± Δt, use TRIGger:A:RUNT:DELTa.
Parameters:
<Range> LONGer | SHORter | WITHin | OUTSide
LONGer
Finds pulses longer than the given width.
SHORter
Finds pulses shorter than the given width.
WITHin
Finds pulses inside the range width ± Δt.
OUTSide
Finds pulses outside the range width ± Δt.
*RST: LONG
TRIGger:A:RUNT:WIDTh <Width>
Sets the reference runt pulse width, the nominal value for comparisons.
Parameters:
<Width> Range: Depends on various settings, mainly time base and
sample rate
17.5.8 Risetime trigger
TRIGger:A:LEVel<n>:RISetime:LOWer............................................................................ 472
TRIGger:A:LEVel<n>:RISetime:UPPer............................................................................. 473
TRIGger:A:RISetime:DELTa............................................................................................ 473
TRIGger:A:RISetime:RANGe.......................................................................................... 473
TRIGger:A:RISetime:SLOPe........................................................................................... 473
TRIGger:A:RISetime:TIME..............................................................................................474
TRIGger:A:LEVel<n>:RISetime:LOWer <Level>
Sets the lower voltage threshold. When the signal crosses this level, the rise time mea-
surement starts or stops depending on the selected slope.
Trigger
