Remote control commands
R&S
®
RTM3000
465User Manual 1335.9090.02 ─ 09
TRIGger:B:MODE <Mode>
Sets a time delay or event delay for the B-trigger. The instrument waits for that delay
after an A-trigger until it recognizes the B-trigger.
Parameters:
<Mode> DELay | EVENts
DELay
Time delay. Set the time with TRIGger:B:DELay.
EVENts
Event delay. Set the number of events with TRIGger:B:
EVENt:COUNt.
*RST: DELay
TRIGger:B:DELay <DelayTime>
Sets the time the instrument waits until it checks the B-trigger condition.
Parameters:
<DelayTime> Range: 20e-9 to 6,871946854
Increment: Depends on the <DelayTime> value. The longer the
time, the higher the increment.
*RST: 20e-9
Default unit: s
TRIGger:B:EVENt:COUNt EventCount
Sets a number of B-trigger events that fulfill the B-trigger condition but do not cause
the trigger. The oscilloscope triggers on the n-th event, the last of the specified number
of events.
Parameters:
EventCount Range: 1 to 65535
Increment: 1
*RST: 1
17.5.4 Width trigger
To set the trigger level (threshold), use:
●
TRIGger:A:LEVel<n>[:VALue] on page 462
CHANnel<m>:THReshold on page 440
●
TRIGger:A:FINDlevel on page 462
CHANnel<m>:THReshold:FINDlevel on page 441
●
CHANnel<m>:THReshold:HYSTeresis on page 441
