Documenting results
R&S
®
RTM3000
225User Manual 1335.9090.02 ─ 09
●
Save reference waveforms.
●
Save search results.
●
Decoded bus data ("Bus Table", requires at least one protocol option for serial bus.
●
Statistical results. OneTouch is the only way to save statistical results.
All data is saved to a ZIP file on the connected USB flash drive.
To configure and use OneTouch:
1. Connect the USB flash drive.
2. Press the [Save Load] key.
3. Enable "OneTouch".
4. Tap "onetouch".
5. Select the target directory ("Destination"), filename, and data you want to save.
6. To save the data now, tap "Save".
7. Close the dialog.
8.
Press the
key each time when you want to save the data.
10.6 Export and import
To copy reference waveforms, formularies (equation sets), and instrument settings
from the internal storage to USB flash drive or vice versa, the "Import Export" functions
are used.
Export and import
