Remote control commands
R&S
®
RTM3000
478User Manual 1335.9090.02 ─ 09
17.6.1 Zoom
TIMebase:ZOOM:STATe................................................................................................. 478
TIMebase:ZOOM:SCALe................................................................................................ 478
TIMebase:ZOOM:TIME...................................................................................................478
TIMebase:ZOOM:POSition..............................................................................................478
DISPlay:CBAR:ZOOM[:POSition].....................................................................................478
TIMebase:ZOOM:STATe <ZoomState>
Switches the zoom on or off.
Parameters:
<ZoomState> ON | OFF
*RST: OFF
TIMebase:ZOOM:SCALe <ZoomScale>
Defines the horizontal scale for the zoom window in seconds per division, the timebase
of the zoom window. The scaling determines the width of the zoom area (12 divisions *
scaling per division).
Parameters:
<ZoomScale> Range: Depends on various settings
*RST: 50e-6
Default unit: s/div
TIMebase:ZOOM:TIME <Time>
Defines the distance of the trigger point to the reference point in the zoom window. The
value determines the position of the zoom area that is displayed in the zoom window.
Parameters:
<Time> *RST: 0
Default unit: s
TIMebase:ZOOM:POSition <Position>
Defines the position of the zoom window in the upper window.
Parameters:
<Position> Range: Depends on the zoom time base, from nearly 0 to
100 % for large zoom.
*RST: 50
Default unit: %
DISPlay:CBAR:ZOOM[:POSition] <DividerPosition>
Defines the position of the divide bar between normal waveform and zoom window.
Waveform analysis
