Remote control commands
R&S
®
RTM3000
479User Manual 1335.9090.02 ─ 09
Parameters:
<DividerPosition> Vertical position in pixel, measured from the top edge. The verti-
cal display size is 800 px.
Default unit: px
17.6.2 Mathematics
To get the data of a math waveform, use the following commands:
●
CALCulate:MATH<m>:DATA? on page 575
●
CALCulate:MATH<m>:DATA:HEADer? on page 575
●
CALCulate:MATH<m>:DATA:POINts? on page 575
●
CALCulate:MATH<m>:DATA:XORigin? on page 579
●
CALCulate:MATH<m>:DATA:XINCrement? on page 579
●
CALCulate:MATH<m>:DATA:YORigin? on page 579
●
CALCulate:MATH<m>:DATA:YINCrement? on page 580
●
CALCulate:MATH<m>:DATA:YRESolution? on page 580
CALCulate:MATH<m>:STATe.......................................................................................... 479
CALCulate:MATH<m>[:EXPRession][:DEFine]..................................................................479
CALCulate:MATH<m>:LABel...........................................................................................481
CALCulate:MATH<m>:LABel:STATe.................................................................................481
CALCulate:MATH<m>:POSition.......................................................................................481
CALCulate:MATH<m>:SCALe......................................................................................... 482
CALCulate:MATH<m>:WCOLor.......................................................................................482
CALCulate:MATH<m>:TRACk:EDGE...............................................................................482
CALCulate:MATH<m>:TRACk:DPULse[:ENABle]..............................................................482
CALCulate:MATH<m>:TRACk:THReshold:HYSTeresis...................................................... 483
CALCulate:MATH<m>:TRACk:THReshold[:UPPer]............................................................483
CALCulate:MATH<m>:TRACk:THReshold:LOWer.............................................................483
CALCulate:MATH<m>:STATe <State>
Activates the mathematics function and displays the defined math waveforms.
Suffix:
<m>
.
1..5
Selects the math waveform.
Parameters:
<State> ON | OFF
*RST: OFF
CALCulate:MATH<m>[:EXPRession][:DEFine] <RemComplExpr>
Defines the equation to be calculated for the selected math waveform as a regular
expression.
Waveform analysis
