Remote control commands
R&S
®
RTM3000
482User Manual 1335.9090.02 ─ 09
CALCulate:MATH<m>:SCALe <Scale>
Sets the vertical scale of the math waveform.
Suffix:
<m>
.
1..5
Selects the math waveform.
Parameters:
<Scale> Scale value, given in Volts per division
Range: -1.0E-24 to 5.0E+25
Increment: Depends on vertical scale, in 1 - 2 - 5 steps (1 mV,
2 mV, 5 mV, 10 mV, 20 mV, 50 mV ...)
*RST: 1
CALCulate:MATH<m>:WCOLor <WaveformColor>
Sets the color of the indicated math waveform.
Suffix:
<m>
.
1..5
Parameters:
<WaveformColor> YELLow | GREen | ORANge | BLUE | LBLUE | WHITE | CYAN |
PINK | RED | TEMPerature | RAINbow | FIRE | DEFault
*RST: DEF
CALCulate:MATH<m>:TRACk:EDGE <Polarity>
Sets the rising or falling edge as a reference for each measurement. The setting helps
to determine values in terms of the power stage switching state.
For unipolar souces, the on edge is the rising edge, and the off edge is the falling
edge.
In the bipolar case, all transitions are inverted for the negative branch. For positive pul-
ses, the rising edge is the on edge, and for negative pulses, the falling edge is the on
edge.
Suffix:
<m>
.
1..5
Parameters:
<Polarity> ON | OFF
CALCulate:MATH<m>:TRACk:DPULse[:ENABle] <DoublePulseEnable>
Available for bipolar signals. Considers the effect of the double pulse, which arises due
to the inversion.
Suffix:
<m>
.
1..5
Waveform analysis
