Remote control commands
R&S
®
RTM3000
475User Manual 1335.9090.02 ─ 09
17.5.10 Serial bus
Triggering on the decoded data of a protocol bus is available if at least one serial proto-
col option is installed. The serial bus must be configured correctly. For detailed infor-
mation on serial protocols and their trigger conditions, see the chapter of the relevant
protocol.
17.5.11 Actions on trigger
To generate a pulse on the Aux Out connector on trigger event, use TRIG
ger:OUT:MODE TRIGger. You can also define the pulse length and polarity with
TRIGger:OUT:PLENgth and TRIGger:OUT:POLarity.
TRIGger:EVENt[:ENABle]............................................................................................... 475
TRIGger:EVENt:SOUNd................................................................................................. 475
TRIGger:EVENt:REFSave.............................................................................................. 476
TRIGger:EVENt:SCRSave.............................................................................................. 476
TRIGger:EVENt:SCRSave:DESTination........................................................................... 476
TRIGger:EVENt:TRIGgerout........................................................................................... 476
TRIGger:EVENt:WFMSave............................................................................................. 477
TRIGger:EVENt:WFMSave:DESTination.......................................................................... 477
TRIGger:EVENt[:ENABle] <EventsEnabled>
Activates the selected actions on trigger event.
To activate the actions, use:
●
TRIGger:EVENt:SOUNd on page 475
●
TRIGger:EVENt:TRIGgerout on page 476
●
TRIGger:EVENt:WFMSave on page 477
●
TRIGger:EVENt:SCRSave on page 476
●
TRIGger:EVENt:REFSave on page 476
Parameters:
<EventsEnabled> ON | OFF
*RST: OFF
TRIGger:EVENt:SOUNd <SoundEnable>
If ON, the instrument generates a beep on trigger event. The acquisition is not delayed,
the sound generation runs asynchronously. The minimum time between two beeps is
1 s. If the instrument triggers faster, not all events are notified by a beep.
Parameters:
<SoundEnable> ON | OFF
*RST: OFF
Trigger
