Remote control commands
R&S
®
RTM3000
487User Manual 1335.9090.02 ─ 09
Suffix:
<m>
.
1..4
Selects the reference waveform.
Parameters:
<Scale> Default unit: V/div
REFCurve<m>:WCOLor <WaveformColor>
Selects a color for the reference waveform. The default color is white. You can select
another monochrome color, or a color scale.
Suffix:
<m>
.
1..4
Selects the reference waveform.
Parameters:
<WaveformColor> YELLow | GREen | ORANge | BLUE | LBLUE | WHITE | CYAN |
PINK | RED | TEMPerature | RAINbow | FIRE | DEFault
*RST: DEF
REFCurve<m>:LABel <WaveformLabel>
Defines a label for the indicated reference waveform.
Suffix:
<m>
.
1..4
Selects the reference waveform.
Parameters:
<WaveformLabel> String parameter
String parameter
Example:
REFCurve2:LABel "Origin"
Sets the label "Origin" for reference R2.
17.6.4 Search
● General search settings........................................................................................ 488
● Edge search configuration.................................................................................... 489
● Width search configuration....................................................................................490
● Peak search configuration.....................................................................................492
● Rise/fall time search configuration........................................................................ 492
● Runt search configuration..................................................................................... 494
● Data2Clock search configuration.......................................................................... 495
● Pattern search configuration................................................................................. 497
● Window search configuration................................................................................499
● Search results....................................................................................................... 501
Waveform analysis
