Operating basics
R&S
®
RTM3000
38User Manual 1335.9090.02 ─ 09
Tap "Back", or tap into the diagram outside the menu.
4.3.2 Accessing functionality using shortcuts
The labels in information bar at the top of the display, the channel labels and also the
results at the bottom provide shortcuts to the most important settings. If you tap a label,
a short menu opens, the keypad for numerical entry, the setting toggles, or the corre-
sponding menu opens. The response depends on the selected parameter.
Figure 4-4: Short menus for channel (left) and trigger slope (right)
From the short menu, you can also open the corresponding comprehensive menu.
You can also switch off the channels.
4.3.3 Entering data
To enter exact numerical values, the instrument provides an on-screen keypad. For
text input, the on-screen keyboard works in the same way.
Using the touchscreen
