Power analysis (option R&S RTM-K31)
R&S
®
RTM3000
359User Manual 1335.9090.02 ─ 09
Gate Count
Sets the number of inrush current gates. You can select up to three gates.
Remote command:
POWer:INRushcurrent:GCOunt on page 730
POWer:INRushcurrent:GATE<n>:STARt on page 729
POWer:INRushcurrent:GATE<n>:STOP on page 729
Set to Screen
Resets the cursors to their initial positions. This is helpful if the cursors have disap-
peared from the display or need to be moved for a larger distance.
14.5 Output power measurements
Output analysis is used to measure the characteristics of the output voltage.
Ripple....................................................................................................................359
Spectrum...............................................................................................................362
Transient response............................................................................................... 365
14.5.1 Ripple
The " Ripple" analysis measures the ripple of the device output. In this measurement
the peak-to peak extremes of the output DC signal are of interest. The measurement
also includes the AC-RMS of the output DC signal, that is calculated as a standard der-
ivation.
14.5.1.1 Ripple results
The results of "Ripple" measurements are:
The voltage waveform
Numeric measurement results
Also, for each measurement result you can enable a statistic evaluation of the mea-
surement results. It returns the current, minimum and maximum measurement values,
the average and standard deviation, and the number of measured waveforms.
The numeric measurement results are defined as follows:
Table 14-3: Properties output ripple
Meas. type Sym-
bol
Description/Result
Peak + Vp+ Maximum value within the displayed section of the waveform.
Peak - Vp- Minimum value within the displayed section of the waveform.
Peak peak Vpp Peak-to-peak value of the waveform: the difference of maximum and mini-
mum values.
X
Ampl
= X
Max
- X
Min
Output power measurements
