Remote control commands
R&S
®
RTM3000
767User Manual 1335.9090.02 ─ 09
POWer:TRANsient:STOP <StopTime>
Sets the stop time for the transient response measurement.
Parameters:
<StopTime>
17.13 Mixed signal option (option R&S RTM-B1)
● Logic channels...................................................................................................... 767
● Parallel buses........................................................................................................774
17.13.1 Logic channels
Two different sets of commands are described in this chapter:
●
LOGic<p>:xxx:xxx:
Refer to the logic pod 1 ("D7...D0") or logic pod 2 ("D8...D15"). The suffix <p>
selects the logic pod, range 1..2.
●
DIGital<m>:xxx:xxx:
Refer to a specific logic channel. The suffix <m> selects the logic channel, range
0..15.
● Logic channels - activity display............................................................................767
● Logic analyzer configuration................................................................................. 768
● Logic channels - waveform data........................................................................... 772
17.13.1.1 Logic channels - activity display
LOGic<p>:PROBe[:ENABle]?..........................................................................................767
LOGic<p>:CURRent:STATe:MAXimum?...........................................................................768
DIGital<m>:CURRent:STATe:MAXimum?......................................................................... 768
LOGic<p>:CURRent:STATe:MINimum?............................................................................ 768
DIGital<m>:CURRent:STATe:MINimum?.......................................................................... 768
LOGic<p>:PROBe[:ENABle]?
Checks if the logic probe is connected.
Suffix:
<p>
.
1..2
Selects the pod.
Return values:
<ProbeEnable> 1 | 0
1 = connected, 0 = not connected
Usage: Query only
Mixed signal option (option R&S RTM-B1)
