Parameters:
<BitsSignals> ON | OFF
*RST: ON
BUS<b>:DSIZe <DisplaySize>
Sets the height of the decoded bus signal on the screen.
Suffix:
<b>
.
1..4
Parameters:
<DisplaySize> SMALl | MEDium | LARGe | DIV2 | DIV4
DIV2 | DIV4
2 or 4 divisions
SMALl | MEDium | LARGe
Size of indicated bus is smaller than 2 div.
*RST: MEDium
BUS<b>:POSition <Position>
Sets the vertical position of the decoded bus signal in divisions on the screen.
Suffix:
<b>
.
1..4
Parameters:
<Position> Range: 5 to -5
Increment: 0.02
*RST: -3.5
Default unit: DIV
BUS<b>:RESult <ShowResultTable>
Displays or hides the table of decode results.
Suffix:
<b>
.
1..4
Parameters:
<ShowResultTable> ON | OFF
17.11.2 SPI (option R&S RTM-K1)
The Serial Peripheral Interface (SPI) is used for communication with slow peripheral
devices, in particular, for transmission of data streams.
SPI (no CS) is a Simplified SPI configuration without chip select line.
Serial bus analysis
