Remote control commands
R&S
®
RTM3000
529User Manual 1335.9090.02 ─ 09
USER: levels are defined with REFLevel:RELative:LOWer,
REFLevel:RELative:MIDDle and REFLevel:RELative:
UPPer.
*RST: TEN
Example:
REFL:REL:MODE TWENty
MEAS2:MAIN RTIM
Sets the reference levels for all measurements and measures
the rise time between these levels for measurement place 2:
lower reference level = 20% of high signal level
upper reference level = 80% of high signal level
REFLevel:RELative:LOWer <LowerLevel>
REFLevel:RELative:UPPer <UpperLevel>
Set the lower and upper reference levels for rise and fall time mesurements (cursor
and automatic mesurements) if REFLevel:RELative:MODE is set to USER. The lev-
els are defined as percentages of the high signal level. They are valid for all measure-
ments.
Parameters:
<LowerLevel> *RST: 10
Default unit: %
<UpperLevel> *RST: 90
Default unit: %
REFLevel:RELative:MIDDle <MiddleLevel>
Set the middle reference level that is used for phase and delay measurements, if
REFLevel:RELative:MODE is set to USER. The level is defined as percentages of
the high signal level. The setting is valid for all measurements.
Parameters:
<MiddleLevel> *RST: 50
Default unit: %
17.7.3 Cursor measurements
17.7.3.1 Cursor settings
CURSor<m>:AOFF........................................................................................................ 530
CURSor<m>:STATe........................................................................................................530
CURSor<m>:FUNCtion...................................................................................................530
CURSor<m>:SOURce....................................................................................................531
CURSor<m>:USSOURce................................................................................................532
CURSor<m>:SSOURce..................................................................................................532
CURSor<m>:TRACking[:STATe]...................................................................................... 532
Measurements
