Power analysis (option R&S RTM-K31)
R&S
®
RTM3000
365User Manual 1335.9090.02 ─ 09
Export
"Export" opens the export menu to save the measurement results. You can set the tar-
get directory, file name, and a comment. The file format is CSV.
Remote command:
EXPort:POWer:NAME on page 729
EXPort:POWer:SAVE on page 729
14.5.3 Transient response
The transient response analysis measures the response of a system to a change from
equilibrium. This response is described by different properties like the overshoot, the
settling time, the peak time and the delay time.
14.5.3.1 Transient response results
The results of "Transient Response" measurements are:
●
Voltage waveform
●
Numeric measurement results
The transient response results are defined as follows:
Table 14-4: Transient response
Result Symbol Description
Rise time tr The time needed for the signal to change from 10% to 90% of the speci-
fied top level.
Overshoot level Ovr The maximum swing level above the top level.
Settling time Sett. The time period between cursor 1 and cursor 2.
Peak time tPeak The time needed for the response to reach the first peak of the over-
shoot.
Peak Peak The peak value of the signal
Delay time Delay The time needed for the response to reach half of the top level value,
after the trigger event.
Remote commands are described in Chapter 17.12.17, "Transient response",
on page 765.
14.5.3.2 Configuring transient response measurements
For details of the configuration settings, see Chapter 14.5.3.3, "Transient response set-
tings", on page 366.
1. Press the Apps Selection key. Tap "Power Analysis".
2. In the "Output" tab, tap "Transient Response".
3. Close the "Power Analysis".
Output power measurements
