Serial bus analysis
R&S
®
RTM3000
338User Manual 1335.9090.02 ─ 09
Minimum Time ← Transmission
Sets the minimum of the transmission time range.
Remote command:
TRIGger:A:ARINc:TTIMe:MINimum on page 706
Maximum Time ← Transmission
Sets the maximum of the transmission time range.
Remote command:
TRIGger:A:ARINc:TTIMe:MAXimum on page 706
13.9.4 ARINC 429 decode results
When the configuration of the serial bus is complete, the signal can be decoded:
1. In the "Bus" menu, enable "Decode".
2. In the "Display" menu, select the result display settings.
See Chapter 13.1.2, "Displaying decode results", on page 253.
3. In the "Bus Table" menu, enable the "Bus Table". Adjust the table settings.
See also: Chapter 13.1.3, "Bus table: decode results", on page 254
The instrument captures and decodes the signal according to the protocol definition
and the configuration settings.
The color-coding of the various protocol sections and errors simplifies the interpretation
of the visual display. The decode information condenses or expands, depending on the
horizontal scale. Various data formats are available to show the result values.
Table 13-8: Content of the ARINC 429 table
Column Description
Start time Time of word start in relation to the trigger point
Stop time Time of word stop in relation to the trigger point
Label name Symbolic label, available if a label list was loaded and applied
Label The value of the label bytes
SDI The state of the SDI bits
SSM The state of the SSM bits
Data The value of the data bytes
State Overall state of the frame
Remote commands are described in Chapter 17.11.9.3, "ARINC 429 decode results",
on page 707.
ARINC 429 (option R&S
RTM-K7)
