Signal generation (option R&S RTM-B6)
R&S
®
RTM3000
410User Manual 1335.9090.02 ─ 09
16.1.5 Burst settings
Access: [Gen] key > "Burst"
With the burst mode, you can output a waveform for a set number of times.
For a step-by-step description of the modulation setup, see "To configure a burst"
on page 403.
Burst
Enables or disables the burst.
Remote command:
WGENerator:BURSt[:STATe] on page 783
N-Cycle
Sets the number of times the generator outputs one cycle of the waveform per burst.
Remote command:
WGENerator:BURSt:NCYCle on page 783
Idle Time
Sets the idle time between two burst cycles.
Remote command:
WGENerator:BURSt:ITIMe on page 783
Start Phase
Sets the start phase of the burst.
Remote command:
WGENerator:BURSt:PHASe on page 783
Function generator
