Remote control commands
R&S
®
RTM3000
474User Manual 1335.9090.02 ─ 09
Parameters:
<Polarity> POSitive | NEGative
POSitive: rise time trigger
NEGative: fall time trigger
*RST: POS
TRIGger:A:RISetime:TIME <RiseTime>
Sets the reference rise or fall time, the nominal value for comparisons.
Parameters:
<RiseTime> Depends on various settings, mainly time base and sample rate
17.5.9 Timeout trigger
To set the trigger level (threshold), use:
●
TRIGger:A:LEVel<n>[:VALue] on page 462
CHANnel<m>:THReshold on page 440
●
TRIGger:A:FINDlevel on page 462
CHANnel<m>:THReshold:FINDlevel on page 441
●
CHANnel<m>:THReshold:HYSTeresis on page 441
TRIGger:A:TIMeout:RANGe............................................................................................474
TRIGger:A:TIMeout:TIME............................................................................................... 474
TRIGger:A:TIMeout:RANGe <Range>
Sets the relation of the signal level to the threshold.
Parameters:
<Range> HIGH | LOW
HIGH
The signal level stays above the trigger level.
LOW
The signal level stays below the trigger level.
*RST: HIGH
TRIGger:A:TIMeout:TIME <Time>
Sets the time limit for the timeout at which the instrument triggers.
Parameters:
<Time> Range: 3.2e-9 to 6.871928
*RST: 10e-6
Trigger
