Documenting results
R&S
®
RTM3000
224User Manual 1335.9090.02 ─ 09
Format
Selects the file format.
●
"BMP": Bitmap is an uncompressed format, files are large and saving can take
some time.
●
"PNG": Portable Network Graphics is a graphic format with lossless data compres-
sion.
Remote command:
HCOPy:FORMat on page 583
Color Mode
Selects the color settings for the screenshot to be saved.
●
"Grayscale": Converts the display colors to a monochrome image
●
"Color": Keeps the original display colors in the screenshot.
●
"Inverted": Inverts the colors of the output, so that a dark waveform is printed on a
white background.
●
"Inverted (gray)": Inverts the colors of the output, and converts to a monochrome
image.
Remote command:
HCOPy:COLor:SCHeme on page 584
Close window & menu
If enabled, open dialog boxes and menus are closed before the screenshot is saved.
Thus, the waveforms and results are always visible on the screenshot.
Remote command:
HCOPy:CWINdow on page 583
Device logo in screenshot
If enabled, the Rohde & Schwarz logo is printed on the screenshot.
Save
Saves the screenshot to the specified file. The used path and filename are displayed
when the storage is completed.
Remote command:
HCOPy[:IMMediate] on page 583
10.5 Quick save with onetouch
The
key initiates one or more assigned saving actions. By default, the key saves a
screenshot.
If OneTouch is enabled, you can assign the following actions to the key:
●
Save instrument settings.
●
Save a screenshot using the settings in [Save Load] > "Screenshots".
●
Save waveforms using the settings in [Save Load] > "Waveforms". If "History Data"
is selected under "Points", this setting is ignored, and the acquired data of the new-
est segment is saved.
Quick save with onetouch
