Remote control commands
R&S
®
RTM3000
654User Manual 1335.9090.02 ─ 09
Parameters:
<DataCondition> EQUal | NEQual | GTHan | LTHan
*RST: EQU
SEARch:PROTocol:CAN:DATA <Data>
Defines the data pattern. The pattern length is defined with SEARch:PROTocol:CAN:
DLENgth.
The command is relevant if SEARch:PROTocol:CAN:CONDition is set to IDData.
Parameters:
<Data> String containing binary pattern with max. 64 bit. Characters 0,
1, and X are allowed. Make sure to enter complete bytes.
17.11.6 LIN (option R&S RTM-K3)
The Local Interconnect Network (LIN) is a simple, low-cost bus system used within
automotive network architectures.
Note: SPI and UART protocols occupy two bus lines (bus 1 and 2 or bus 3 and 4). If
one of these buses is configured, the number of buses (suffix <b>) is reduced. Bus 2
and/or bus 4 is not available.
● LIN - configuration.................................................................................................654
● LIN - trigger........................................................................................................... 655
● LIN - decode results..............................................................................................658
● LIN - search...........................................................................................................664
17.11.6.1 LIN - configuration
Start the bus configuration with the threshold setting. Use one of the following com-
mands:
●
CHANnel<m>:THReshold:FINDlevel on page 441
●
CHANnel<m>:THReshold on page 440
In all BUS<b>:LIN... commands, the suffix <b> selects the bus.
BUS<b>:LIN:DATA:SOURce........................................................................................... 654
BUS<b>:LIN:POLarity.....................................................................................................655
BUS<b>:LIN:STANdard.................................................................................................. 655
BUS<b>:LIN:BITRate..................................................................................................... 655
BUS<b>:LIN:DATA:SOURce <Source>
Sets the source of the data line. All channel waveforms can be used.
Suffix:
<b>
.
1..4
Serial bus analysis
