Remote control commands
R&S
®
RTM3000
655User Manual 1335.9090.02 ─ 09
Parameters:
<Source> CH1 | CH2 | CH3 | CH4 | D0..D15
*RST: CH1
BUS<b>:LIN:POLarity <Polarity>
Defines the idle state of the bus. The idle state is the recessive state and corresponds
to a logic 1.
Suffix:
<b>
.
1..4
Parameters:
<Polarity> IDLHigh | IDLLow
IDLHigh: Low active, negative polarity
IDLLow: High active, positive polarity
*RST: IDLL
BUS<b>:LIN:STANdard
<Standard>
Selects the version of the LIN standard that is used in the DUT. The setting mainly
defines the checksum version used during decoding.
The most common version is LIN 2.x. For mixed networks, or if the standard is
unknown, set the LIN standard to AUTO.
Suffix:
<b>
.
1..4
Parameters:
<Standard> V1X | V2X | J2602 | AUTO
*RST: V1X
BUS<b>:LIN:BITRate <BitRate>
Sets the number of transmitted bits per second.
Suffix:
<b>
.
1..4
Parameters:
<BitRate> Range: 100 bit/s to 5 Mbit/s
*RST: 9,6E03
Default unit: Bit/s
17.11.6.2 LIN - trigger
To configure the protocol trigger, make sure to set first:
●
TRIGger:A:TYPE to BUS
Serial bus analysis
