Remote control commands
R&S
®
RTM3000
461User Manual 1335.9090.02 ─ 09
CH1 | CH2 | CH3 | CH4
One of the analog input channels is the trigger source. Available
channels depend on the instrument type.
EXTernanalog
External trigger input on the front panel
LINE
AC power supply line for the line trigger
SBUS1 | SBUS2
Serial bus 1 or 2
Requires at least one protocol option for serial bus (R&S RTM-
K1 to K3)
D0..D15
Digital channels D0 to D15, can be used as trigger sources for
edge, width, timeout and pattern trigger. Require MSO option
R&S RTM-B1.
TRIGger:A:TYPE <Type>
Sets the trigger typer.
Parameters:
<Type> EDGE | WIDTh | TV | BUS | LOGic | LINE | RISetime | RUNT
EDGE
Edge trigger
WIDTh
Width trigger
TV
Video trigger
BUS
Requires at least one protocol option for serial bus (R&S RTM-
K1 to K3)
LOGic
Pattern trigger, logic trigger
LINE
Trigger on power supply line
RISetime
Trigger on rise and fall time (transition trigger)
RUNT
Trigger on runts, on pulses with smaller amplitude
TRIGger:A:HOLDoff:MODE <HoldOffMode>
Enables or disables the holdoff time.
Parameters:
<HoldOffMode> TIME | OFF
*RST: Off
