Remote control commands
R&S
®
RTM3000
787User Manual 1335.9090.02 ─ 09
WGENerator:SWEep:TIME <SweepTime>
Sets the duration of the sweep.
Parameters:
<SweepTime>
WGENerator:SWEep:TYPE <SweepType>
Sets the type of the sweep, a linear, logarithmic or triangle-shaped change of the fre-
quency.
Parameters:
<SweepType> LINear | LOGarithmic | TRIangle
WGENerator:SWEep[:ENABle]
<SweepEnable>
Enables or disables sweeping.
Parameters:
<SweepEnable> ON | OFF
17.14.2 Pattern generator
● General settings....................................................................................................787
● Square wave......................................................................................................... 789
● Counter pattern..................................................................................................... 790
● Arbitrary pattern.................................................................................................... 791
● Manual pattern...................................................................................................... 793
● PWM signals......................................................................................................... 794
17.14.2.1 General settings
PGENerator:FUNCtion................................................................................................... 787
PGENerator:PATTern:STATe........................................................................................... 788
PGENerator:OUTPut:VOLTage........................................................................................788
PGENerator:PATTern:TRIGger:EXTern:SLOPe................................................................. 789
PGENerator:FUNCtion <PatternFunction>
Selects the pattern generator function.
Parameters:
<PatternFunction> SQUarewave | COUNter | ARBitrary | SPI | I2C | UART | CAN |
LIN | MANual | I2S | TDM | TPWM | PWM | LEDPwm
SQUarewave
Square wave function (e.g. for manual probe compensation).
Signal generation (option R&S RTM-B6)
