Remote control commands
R&S
®
RTM3000
788User Manual 1335.9090.02 ─ 09
COUNter
Definition of a 4-bit wide counter pattern.
ARBitrary
Definition of a 4-bit wide and 2048 samples deep pattern.
SPI
SPI BUS signals for measurements without measurement
object. Data rate 100 kBit/s, 250 kBit/s or 1 MBit/s.
I2C
I
2
C BUS signals for measurements without measurement object.
Data rate 100 kBit/s, 400 kBit/s, 1 MBit/s or 3.4 MBit/s.
UART
UART BUS signals for measurements without measurement
object. Data rate 9600 Bit/s, 115.2 kBit/s and 1 MBit/s.
CAN
CAN BUS signals for measurements without measurement
object up to 50 MBit/s.
LIN
LIN BUS signals for measurements without measurement object
up to 50 MBit/s.
MANual
Manual pattern mode.
l2S
Audio-I2S BUS signal.
TDM
Audio-TDM BUS signal.
TPWM
Test signals with pulse width modulation.
PWM
Pulse width modulated signal.
LEDPwm
Pulse width modulated signal for LED color control.
*RST:
SQUarewave
PGENerator:PATTern:STATe <State>
Activates or deactivates the pattern.
Parameters:
<State> ON | OFF
*RST: OFF
PGENerator:OUTPut:VOLTage <OutputVoltage>
Sets the output voltage of the generated pattern signal.
Signal generation (option R&S
RTM-B6)
