Remote control commands
R&S
®
RTM3000
604User Manual 1335.9090.02 ─ 09
Setting parameters:
<Path> Empty string
Example: See Chapter 17.2.2.2, "Using DIAGnostic:UPDdate:TRANsfer",
on page 428
Usage: Setting only
17.11 Serial bus analysis
● General................................................................................................................. 604
● SPI (option R&S RTM-K1).................................................................................... 606
● I²C (option R&S RTM-K1)..................................................................................... 619
● UART (option R&S RTM-K2)................................................................................ 629
● CAN (option R&S RTM-K3)...................................................................................638
● LIN (option R&S RTM-K3).....................................................................................654
● Audio (option R&S RTM-K5).................................................................................667
● MIL-1553 (option R&S RTM-K6)...........................................................................679
● ARINC 429 (option R&S RTM-K7)........................................................................701
17.11.1 General
BUS<b>:TYPE...............................................................................................................604
BUS<b>:STATe..............................................................................................................604
BUS<b>:FORMat...........................................................................................................605
BUS<b>:LABel.............................................................................................................. 605
BUS<b>:LABel:STATe.................................................................................................... 605
BUS<b>:DSIGnals......................................................................................................... 605
BUS<b>:DSIZe..............................................................................................................606
BUS<b>:POSition.......................................................................................................... 606
BUS<b>:RESult.............................................................................................................606
BUS<b>:TYPE <Type>
Defines the bus or interface type for analysis. All buses require special option to the
instrument.
Suffix:
<b>
.
1..4
Parameters:
<Type> PARallel | CPARallel | I2C | SPI | SSPI | UART | CAN | LIN | I2S |
MILStd | ARINc
*RST: PARallel
BUS<b>:STATe <State>
Switches protocol decoding on or off.
Serial bus analysis
