Remote control commands
R&S
®
RTM3000
667User Manual 1335.9090.02 ─ 09
17.11.7 Audio (option R&S RTM-K5)
● Audio configuration............................................................................................... 667
● Audio trigger..........................................................................................................672
● Audio decode results.............................................................................................676
17.11.7.1 Audio configuration
BUS<b>:I2S:AVARiant....................................................................................................667
BUS<b>:I2S:BORDer..................................................................................................... 667
BUS<b>:I2S:CHANnel:LENGth....................................................................................... 668
BUS<b>:I2S:CHANnel:OFFSet........................................................................................668
BUS<b>:I2S:CHANnel:ORDer.........................................................................................668
BUS<b>:I2S:CHANnel:TDMCount................................................................................... 668
BUS<b>:I2S:CLOCk:POLarity......................................................................................... 669
BUS<b>:I2S:CLOCk:SOURce.........................................................................................669
BUS<b>:I2S:CLOCk:THReshold......................................................................................669
BUS<b>:I2S:DATA:POLarity............................................................................................669
BUS<b>:I2S:DATA:SOURce............................................................................................670
BUS<b>:I2S:DATA:THReshold........................................................................................ 670
BUS<b>:I2S:DISPlay......................................................................................................670
BUS<b>:I2S:FOFFset.....................................................................................................671
BUS<b>:I2S:WLENgth................................................................................................... 671
BUS<b>:I2S:WSELect:POLarity...................................................................................... 671
BUS<b>:I2S:WSELect:SOURce...................................................................................... 672
BUS<b>:I2S:WSELect:THReshold...................................................................................672
BUS<b>:I2S:AVARiant <AudioVariant>
Selects the protocol variant of the audio signal.
Suffix:
<b>
.
1..4
Parameters:
<AudioVariant> I2S | LJ | RJ | TDM | DSP
I2S: Inter-IC sound standard audio format.
LJ: left justified data format
RJ: right justified data format
TDM: time division multiplexed audio format to transfer up to 8
audio data channels on one line
*RST: I2S
BUS<b>:I2S:BORDer <BitOrder>
Sets the bit order in the audio data words. Usually, the MSB is transmitted first.
Suffix:
<b>
.
1..4
Serial bus analysis
