Remote control commands
R&S
®
RTM3000
672User Manual 1335.9090.02 ─ 09
INVert
0 indicates the right channel, and 1 the left channel.
TDM: the frame begins with a falling edge.
*RST: NORM
BUS<b>:I2S:WSELect:SOURce <WordSelectSource>
Selects the source of the word select line.
Suffix:
<b>
.
1..4
Parameters:
<WordSelectSource> CH1 | CH2 | CH3 | CH4 | D0..15
CH3 and CH4 are only available with 4-channel R&S RTM3000
oscilloscopes.
*RST: CH1
BUS<b>:I2S:WSELect:THReshold
<Threshold>
Sets the threshold for the indicated audio line.
Suffix:
<b>
.
1..4
Parameters:
<Threshold> s
*RST: 1.4
17.11.7.2 Audio trigger
BUS<b>:I2S:FCOunt?.................................................................................................... 673
TRIGger:A:I2S:CHANnel:LEFT:CONDition........................................................................673
TRIGger:A:I2S:CHANnel:LEFT:DMAX..............................................................................673
TRIGger:A:I2S:CHANnel:LEFT:DMIN...............................................................................673
TRIGger:A:I2S:CHANnel:RIGHt:CONDition...................................................................... 674
TRIGger:A:I2S:CHANnel:RIGHt:DMAX............................................................................ 674
TRIGger:A:I2S:CHANnel:RIGHt:DMIN..............................................................................674
TRIGger:A:I2S:CHANnel:TDM<n>:CONDition...................................................................674
TRIGger:A:I2S:CHANnel:TDM<n>:DMAX.........................................................................675
TRIGger:A:I2S:CHANnel:TDM<n>:DMIN..........................................................................675
TRIGger:A:I2S:FUNCtion................................................................................................675
TRIGger:A:I2S:TYPE......................................................................................................675
TRIGger:A:I2S:SOWords................................................................................................ 676
TRIGger:A:I2S:WINDow:LENGth.....................................................................................676
TRIGger:A:I2S:WSELect:SLOPe..................................................................................... 676
TRIGger:A:I2S:WSSLope................................................................................................676
Serial bus analysis
