Remote control commands
R&S
®
RTM3000
675User Manual 1335.9090.02 ─ 09
EQUal | NEQual | GTHan | LTHan
Equal, not equal, greater than, less than. These conditions
require one data word to be set with TRIGger:A:I2S:
CHANnel:TDM<n>:DMIN.
TRIGger:A:I2S:CHANnel:TDM<n>:DMAX <MaximumValue>
Specifies the maximum data value to be found, if TRIGger:A:I2S:CHANnel:
TDM<n>:CONDition is set to INRange or OORange
Parameters:
<MaximumValue> The data format is decimal. The maximum value is limited by the
word length. Consider that audio words are signed numbers in
2's complement format. For example, an 8-bit data word has a
value range from -128 to 127.
TRIGger:A:I2S:CHANnel:TDM<n>:DMIN
<MinimumValue>
Specifies a data pattern, or sets the the start value of a data pattern range.
Parameters:
<MinimumValue>
TRIGger:A:I2S:FUNCtion <Function>
Sets the logical combination to trigger on data words on different channels. The instru-
ment triggers if all conditions are met inside one frame.
The setting is relevant, if TRIGger:A:I2S:TYPE is set to DATA or WINDow.
Parameters:
<Function> AND | OR
TRIGger:A:I2S:TYPE <TriggerMode>
Specifies the trigger mode for audio signals.
Parameters:
<TriggerMode> DATA | WINDow | WSELect | ERRCondition
DATA
Triggers on a data word or a data range that occurs on a speci-
fied channel. You can also trigger on an AND combination of
data conditions on different channels.
Use the TRIGger:A:I2S:CHANnel:LEFT:CONDition com-
mands to define the data condition.
To set the logical combination to trigger on data words on differ-
ent channels, use TRIGger:A:I2S:FUNCtion.
Serial bus analysis
