Power analysis (option R&S RTM-K31)
R&S
®
RTM3000
353User Manual 1335.9090.02 ─ 09
Restart
Restarts the consumption measurement.
Remote command:
POWer:CONSumption:RESTart on page 718
14.4.3 Harmonics
Current harmonics analysis measures the amplitude of frequency components that can
be injected back into the AC lines. Therefore, FFT analysis with flat top window is per-
formed. Current harmonics analysis also performs pre-compliance testing according to
standards EN 61000-3-2 A / B / C / D.
14.4.3.1 Harmonics results
The results of "Harmonics" measurements are:
●
The voltage waveform
●
The current waveform
●
Numeric measurement results
●
A bar that displays the measured value of the harmonics related to the value
defined in the standard
You can export the results to file.
Table 14-2: Harmonics results
Result Table Description
Order The harmonic order
Frequency The frequency value of the signal
Level The level of the harmonic
Minimum The minimum measured value
Maximum The maximum measured value
Average The average level of the harmonic
Limit bar chart The value defined in the standard (white bar) and the measured value of the har-
monics (green: value within the standard's defined limit; red: value out of the
standard's defined limit)
Limit The limit for the harmonic
Remote commands are described in Chapter 17.12.7, "Current harmonic",
on page 723.
14.4.3.2 Configuring harmonics measurements
For details of the configuration settings, see Chapter 14.4.3.3, "Harmonics settings",
on page 354.
