Remote control commands
R&S
®
RTM3000
549User Manual 1335.9090.02 ─ 09
Return values:
<Yincrement>
Usage: Query only
SPECtrum:WAVeform:AVERage:DATA:YORigin?
SPECtrum:WAVeform:MAXimum:DATA:YORigin?
SPECtrum:WAVeform:MINimum:DATA:YORigin?
SPECtrum:WAVeform:SPECtrum:DATA:YORigin?
Returns the vertical bit resolution of the indicated waveform.
Return values:
<Yorigin>
Usage: Query only
SPECtrum:WAVeform:AVERage:DATA:YRESolution?
SPECtrum:WAVeform:MAXimum:DATA:YRESolution?
SPECtrum:WAVeform:MINimum:DATA:YRESolution?
SPECtrum:WAVeform:SPECtrum:DATA:YRESolution?
Returns the vertical bit resolution of the indicated waveform.
Return values:
<Yresolution>
Usage: Query only
17.8.4 Spectrum analysis and spectrogram (options R&S RTM-K18/K37)
● Spectrogram..........................................................................................................549
● Peak list settings................................................................................................... 550
● Reference marker................................................................................................. 552
● Peak list results.....................................................................................................554
● Display settings for spectrum and spectrogram....................................................556
17.8.4.1 Spectrogram
SPECtrum:MODE
Switches between basic FFT analysis and and advanced spectrum analysis. Spectrum
analysis requirese option R&S RTM-K18 or K37.
Parameters:
<Mode> FFT | SPECtrumanalysis
SPECtrum:SPECtrogram:RESet
Resets the current spectrogram and starts a new recording of information.
