Remote control commands
R&S
®
RTM3000
483User Manual 1335.9090.02 ─ 09
Parameters:
<DoublePulseEnable>ON | OFF
CALCulate:MATH<m>:TRACk:THReshold:HYSTeresis <Hysteresis>
Sets the hysteresis for correct edge detection.
Suffix:
<m>
.
1..5
Parameters:
<Hysteresis> Default unit: V
CALCulate:MATH<m>:TRACk:THReshold[:UPPer]
<ThresholdLevel>
Sets the threshold for unipolar track sources, or the upper level for bipolar sources.
The signal is measured at the crossing points of the signal with the threshold.
Suffix:
<m>
.
1..5
Parameters:
<ThresholdLevel> Default unit: V
CALCulate:MATH<m>:TRACk:THReshold:LOWer <ThresholdLevel>
Sets the lower level for bipolar track sources, which determines the crossing points on
negative pulses.
Suffix:
<m>
.
1..5
Parameters:
<ThresholdLevel> Default unit: V
17.6.3 Reference waveforms
In all REFCurve:... commands, the suffix <m> selects the reference waveform.
To get the waveform data, use the following commands:
●
REFCurve<m>:DATA? on page 576
●
REFCurve<m>:DATA:HEADer? on page 576
●
REFCurve<m>:DATA:XINCrement? on page 579
●
REFCurve<m>:DATA:XORigin? on page 579
●
REFCurve<m>:DATA:YINCrement? on page 580
●
REFCurve<m>:DATA:YORigin? on page 580
●
REFCurve<m>:DATA:YRESolution? on page 580
Waveform analysis
