Remote control commands
R&S
®
RTM3000
576User Manual 1335.9090.02 ─ 09
Usage: Query only
17.9.1.4 Reference waveforms
In addition to the commands described below, consider also the following commands:
●
REFCurve<m>:DATA:XINCrement? on page 579
●
REFCurve<m>:DATA:XORigin? on page 579
●
REFCurve<m>:DATA:YINCrement? on page 580
●
REFCurve<m>:DATA:YORigin? on page 580
●
REFCurve<m>:DATA:YRESolution? on page 580
REFCurve<m>:DATA?
Returns the data of the reference waveform for transmission from the instrument to the
controlling computer. The waveforms data can be used in MATLAB, for example.
To set the export format, use FORMat[:DATA] on page 569.
Suffix:
<m>
.
1..4
Selects the reference waveform, the internal reference storage.
Return values:
<Data> List of values according to the format settings.
Usage: Query only
REFCurve<m>:DATA:HEADer?
Returns information on the reference waveform.
Table 17-4: Header data
Position Meaning Example
1 XStart in s -9.477E-008 = - 94,77 ns
2 XStop in s 9.477E-008 = 94,77 ns
3 Record length of the waveform in Samples 200000
4 Number of values per sample interval, usually 1. 1
Suffix:
<m>
.
1..4
Selects the reference waveform, the internal reference storage.
Parameters:
<Header> Comma-separated value list
Example: -9.477E-008,9.477E-008,200000,1
Usage: Query only
