17.9.1.5 Masks
In addition to the commands described below, consider also the following commands:
●
MASK:DATA:XINCrement? on page 579
●
MASK:DATA:XORigin? on page 579
●
MASK:DATA:YINCrement? on page 580
●
MASK:DATA:YORigin? on page 579
●
MASK:DATA:YRESolution? on page 580
MASK:DATA?
Returns the data of the mask. The mask consists of two limit curves.
To set the export format, use FORMat[:DATA] on page 569.
Return values:
<Data> List of values according to the format settings - the y-values of
the mask points. The list contains two values for each sample
interval.
Usage: Query only
MASK:DATA:HEADer?
Returns information on the mask data that is delivered with MASK:DATA?.
Table 17-5: Header data
Position Meaning Example
1 XStart in s -9.477E-008 = - 94,77 ns
2 XStop in s 9.477E-008 = 94,77 ns
3 Number of samples 200000
4 Number of values per sample interval. For masks
the value is 2.
2
Return values:
<DataHeader> Comma-separated value list
Example: -9.477E-008,9.477E-008,200000,2
Usage: Query only
17.9.1.6 Logic channels
See Chapter 17.13.1.3, "Logic channels - waveform data", on page 772
