Parameters:
<Contents> Contents of the service request enable register in decimal form.
Bit 6 (MSS mask bit) is always 0.
Range: 0 to 255
*STB?
Status byte query
Reads the contents of the status byte in decimal form.
Usage: Query only
*TRG
Trigger
Triggers all actions waiting for a trigger event. In particular, *TRG generates a manual
trigger signal. This common command complements the commands of the TRIGger
subsystem.
Usage:
Event
*WAI
Wait to continue
Prevents servicing of the subsequent commands until all preceding commands have
been executed and all signals have settled (see also command synchronization and
*OPC).
Usage:
Event
17.4 Waveform setup
● Automatic setup.................................................................................................... 434
● Starting and stopping acquisition.......................................................................... 434
● Vertical settings.....................................................................................................435
● Passive probes......................................................................................................442
● Active probes........................................................................................................ 443
● R&S ProbeMeter...................................................................................................450
● Horizontal settings.................................................................................................452
● Acquisition settings............................................................................................... 454
● Waveform data......................................................................................................459
