1.684724e-04,0,WIDTH,POSITIVE,1.215160e-05,10,1.953216e-04,0,WIDTH,POSITIVE,
3.027200e-06,11,2.044716e-04,0,WIDTH,POSITIVE,6.052000e-06,12,2.252212e-04,0,
WIDTH,POSITIVE,3.052000e-06,13,2.435456e-04,0,WIDTH,POSITIVE,3.027200e-06,14,
2.496456e-04,0,WIDTH,POSITIVE,6.702000e-06
17.2.4 Function generator
Configure and output a sine waveform.
Command description in: Chapter 17.14.1, "Function generator", on page 779.
Prerequesite: To see the generated waveform on the oscilloscope, connect the "Gen"
output to "Ch1" input.
*RST
WGEN:FUNC SIN // Selects sine function
WGEN:VOLT 700E-3 // Sets the amplitude
WGEN:FREQ 1.00E+06 // Sets the frequency
WGEN:OUTP:LOAD R50 // Sets the user load
WGEN:OUTP 1 // Outputs the sine waveform
AUT // Autoscale to see the waveform
17.3 Common commands
Common commands are described in the IEEE 488.2 (IEC 625-2) standard. These
commands have the same effect and are employed in the same way on different devi-
ces. The headers of these commands consist of "*" followed by three letters. Many
common commands are related to the Status Reporting System.
Available common commands:
*CAL?...........................................................................................................................430
*CLS.............................................................................................................................431
*ESE.............................................................................................................................431
*ESR?...........................................................................................................................431
*IDN?............................................................................................................................431
*OPC............................................................................................................................431
*OPT?...........................................................................................................................432
*PSC............................................................................................................................ 432
*RST.............................................................................................................................432
*SRE............................................................................................................................ 432
*STB?...........................................................................................................................433
*TRG............................................................................................................................ 433
*WAI.............................................................................................................................433
*CAL?
Performs a self-alignment of the instrument and then generates a status response.
Return values ≠ 0 indicate an error.
Common commands
