Remote control commands
R&S
®
RTM3000
467User Manual 1335.9090.02 ─ 09
Parameters:
<Time1> Center value, maximum value or minimum value depending on
the defined range type.
Range: 20E-9 to 6.87194685440
Increment: Depends on the <Time1> value
*RST: 20E-9
TRIGger:A:WIDTh:DELTa <Delta>
Defines a variation range around the width value specified using TRIGger:A:WIDTh:
WIDTh.
Parameters:
<Delta> Variation ±Δt
Range: Minimum is 0. Maximum depends on the defined
pulse width (TRIG:A:WIDTH:WITDH).
17.5.5 Video/TV trigger
TRIGger:A:TV:STANdard................................................................................................ 467
TRIGger:A:TV:POLarity.................................................................................................. 467
TRIGger:A:TV:FIELd...................................................................................................... 468
TRIGger:A:TV:LINE........................................................................................................468
TRIGger:A:TV:STANdard <Standard>
Selects the color television standard.
Parameters:
<Standard> PAL | NTSC | SECam | PALM | I576 | P720 | P1080 | I1080
PALM = PAL-M
I576 = SDTV 576i (PAL and SECAM)
P720 | P1080 = HDTV 720/1080p (progressive scanning)
I1080 = HDTV 1080i (interlaced scanning)
*RST: PAL
TRIGger:A:TV:POLarity <Polarity>
Selects the polarity of the signal. Note that the sync pulse has the opposite polarity.
The edges of the sync pulses are used for triggering,
See also: "Signal" on page 90
Parameters:
<Polarity> POSitive | NEGative
POSitive
If the video modulation is positive, the sync pulses are negative.
Trigger
