Rohde & Schwarz RTM3K-COM2

Remote control commands
R&S
®
RTM3000
542User Manual 1335.9090.02 ─ 09
●
MASK:DATA:YINCrement? on page 580
●
MASK:DATA:YORigin? on page 579
●
MASK:DATA:YRESolution? on page 580
17.8.3 FFT analysis
● General settings....................................................................................................542
● Frequency settings................................................................................................544
● Time settings.........................................................................................................545
● Waveform settings................................................................................................ 546
● Waveform data......................................................................................................547
17.8.3.1 General settings
SPECtrum[:STATe]......................................................................................................... 542
SPECtrum:SOURce....................................................................................................... 542
SPECtrum:FREQuency:WINDow:TYPE........................................................................... 542
SPECtrum:FREQuency:MAGNitude:SCALe......................................................................543
SPECtrum:FREQuency:POSition.....................................................................................543
SPECtrum:FREQuency:SCALe....................................................................................... 544
DISPlay:CBAR:FFT[:POSition]........................................................................................ 544
SPECtrum[:STATe]
Switches on the spectrum analysis.
Parameters:
<State> ON | OFF
SPECtrum:SOURce
Selects the source for the spectrum analysis diagrams.
Parameters:
<Source> CH1 | CH2 | CH3 | CH4
SPECtrum:FREQuency:WINDow:TYPE
Window functions are multiplied with the input values and thus can improve the spec-
trum analysis display.
Parameters:
<WindowFunction> RECTangular | HAMMing | HANNing | BLACkmanharris |
FLATtop
Applications
