Remote control commands
R&S
®
RTM3000
789User Manual 1335.9090.02 ─ 09
Parameters:
<OutputVoltage> Default unit: Hz
PGENerator:PATTern:TRIGger:EXTern:SLOPe
Defines the slope of the external arbitrary pattern trigger.
Parameters:
<ExternSlope> POSitive | NEGative | EITHer
POSitive
Rising edge (rise).
NEGative
Falling edge (fall).
EITHer
Rising as well as the falling edge (both).
*RST: POSitive
17.14.2.2
Square wave
PGENerator:PATTern:SQUarewave:POLarity....................................................................789
PGENerator:PATTern:SQUarewave:DCYCle.....................................................................789
PGENerator:PATTern:PERiod..........................................................................................789
PGENerator:PATTern:FREQuency................................................................................... 790
PGENerator:PATTern:SQUarewave:POLarity <Polarity>
Defines the polarity of the pattern generator square wave function.
Parameters:
<Polarity> NORMal | INVerted
*RST: NORM
PGENerator:PATTern:SQUarewave:DCYCle <DutyCycle>
Sets the duty cycle of the square wave function.
Parameters:
<DutyCycle> Numeric value
Range: 1.00E+00 to 9.900E+01
*RST: 5.000E+01
Default unit: %
Example: PGEN:PATT:SQU:DCYC 20
Sets the duty cycle of the square wave function to 20%.
PGENerator:PATTern:PERiod <PatternPeriod>
Defines the period of the pattern generator function.
Signal generation (option R&S
RTM-B6)
