Remote control commands
R&S
®
RTM3000
791User Manual 1335.9090.02 ─ 09
17.14.2.4 Arbitrary pattern
PGENerator:PATTern:TRIGger:MODE..............................................................................791
PGENerator:PATTern:ARBitrary:DATA[:SET].....................................................................791
PGENerator:PATTern:ARBitrary:DATA:LENGth................................................................. 791
PGENerator:PATTern:ARBitrary:DATA:APPend.................................................................791
PGENerator:PATTern:ARBitrary:DATA:APPend:BOR......................................................... 792
PGENerator:PATTern:ARBitrary:DATA:APPend:BAND....................................................... 792
PGENerator:PATTern:ARBitrary:DATA:APPend:INDex....................................................... 792
PGENerator:PATTern:TRIGger:SINGle.............................................................................792
PGENerator:PATTern:STIMe........................................................................................... 792
PGENerator:PATTern:ITIMe............................................................................................ 793
PGENerator:PATTern:BURSt:STATe.................................................................................793
PGENerator:PATTern:BURSt:NCYCle.............................................................................. 793
PGENerator:PATTern:TRIGger:MODE <TriggerMode>
Defines the arbitrary trigger mode of the pattern generator function.
Parameters:
<TriggerMode> CONTinuous | SINGle
CONTinuous
The CONT function (continuous trigger) issues the pattern con-
tinuously.
SINGle
If the SING setting is activated, the pattern is issued manually.
*RST: CONT
PGENerator:PATTern:ARBitrary:DATA[:SET] <ArbitraryData>
Defines the arbitrary pattern.
Parameters:
<ArbitraryData> List of Values
Example: PGEN:PATT:ARB:DATA 0,1,1,1,2,0,3,1,4,0
PGENerator:PATTern:ARBitrary:DATA:LENGth <PatternLength>
Defines the arbitrary pattern length.
Parameters:
<PatternLength> Numeric value
Range: 1 to 2048
*RST: 1
PGENerator:PATTern:ARBitrary:DATA:APPend <AppendData>
Defines the arbitrary pattern.
Signal generation (option R&S
RTM-B6)
