Remote control commands
R&S
®
RTM3000
792User Manual 1335.9090.02 ─ 09
Setting parameters:
<AppendData> List of Values
Example: PGEN:PATT:ARB:DATA:APP 4
From index = n, the oscilloscope appends a 4 in HEX to the
pattern.
Usage: Setting only
PGENerator:PATTern:ARBitrary:DATA:APPend:BOR <AppendData>
From index = n, data will be integrated in existing pattern via OR combination.
Setting parameters:
<AppendData> List of Values
Usage: Setting only
PGENerator:PATTern:ARBitrary:DATA:APPend:BAND
<AppendData>
From index = n, data will be integrated in existing pattern via AND combination.
Setting parameters:
<AppendData> List of Values
Usage: Setting only
PGENerator:PATTern:ARBitrary:DATA:APPend:INDex <AppendIndex>
Defines the index of the arbitrary pattern.
Parameters:
<AppendIndex> Numeric value
Example: PGEN:PATT:ARB:DATA:APP:IND 5
PGEN:PATT:ARB:DATA:APP 4
From index = n, a pattern length of 6 will be defined with last
high bit 4.
PGENerator:PATTern:TRIGger:SINGle
Manual output of a pattern (single trigger).
Usage:
Event
PGENerator:PATTern:STIMe <SampleTime>
Sets the time at which each sample is applied for the pattern generator function.
Signal generation (option R&S
RTM-B6)
