Remote control commands
R&S
®
RTM3000
786User Manual 1335.9090.02 ─ 09
WGENerator:MODulation:FSK:HFREquency <HoppingFrequency>
Sets the second frequency of the FSK-modulated signal.
Parameters:
<HoppingFrequency> The range depends on the signal type:
Sinus: 100mHz - 25MHz
Sinc/Triangle/Ramp/Exponential: 100mHz - 1MHz
Rectangle/Pulse/Arbitrary: 100mHz - 10MHz
WGENerator:MODulation:FSK:RATE <Rate>
Sets the rate at which signal switches between the carrier frequency and the hopping
frequency.
Parameters:
<Rate> Range: 0.1 to 1E6
Default unit: Hz
WGENerator:MODulation:RAMP:POLarity <Polarity>
Sets the polarity for the ramp function for a modulation waveform.
Parameters:
<Polarity> POSitive | NEGative
17.14.1.5 Sweep settings
WGENerator:SWEep:FEND............................................................................................ 786
WGENerator:SWEep:FSTart........................................................................................... 786
WGENerator:SWEep:TIME............................................................................................. 787
WGENerator:SWEep:TYPE............................................................................................ 787
WGENerator:SWEep[:ENABle]........................................................................................787
WGENerator:SWEep:FEND <StopFrequency>
Sets the stop frequency of the sweep signal.
Parameters:
<StopFrequency>
WGENerator:SWEep:FSTart <StartFrequency>
Sets the start frequency of the sweep signal.
Parameters:
<StartFrequency>
Signal generation (option R&S RTM-B6)
