Rohde & Schwarz RTM3K-COM2 User Manual

Remote control commands
R&S
®
RTM3000
794User Manual 1335.9090.02 ─ 09
OFF
Pin state is set to low (L).
*RST: OFF
Example: PGEN:MAN:STAT2 ON
Sets the state of pin S2 to high (H).
17.14.2.6 PWM signals
PGENerator:PATTern:PWM:DCYCle................................................................................ 794
PGENerator:PATTern:PWM:DIRection..............................................................................794
PGENerator:PATTern:PWM:ENABle.................................................................................794
PGENerator:PATTern:LED:BLUE..................................................................................... 794
PGENerator:PATTern:LED:GREen...................................................................................794
PGENerator:PATTern:LED:RED.......................................................................................794
PGENerator:PATTern:LED:INTens................................................................................... 795
PGENerator:PATTern:PWM:DCYCle <DutyCycle>
Sets the duty cycle of the PWM signal at P0, and thus the motor speed.
Parameters:
<DutyCycle> Range: 1 to 99
Increment: 1
*RST: 50
Default unit: %
PGENerator:PATTern:PWM:DIRection <Direction>
Sets the direction of motor rotation.
Parameters:
<Direction> POSitive | NEGative
PGENerator:PATTern:PWM:ENABle <Enable>
Switches the motor on or off if the motor driver uses a dedicated enable signal.
Parameters:
<Enable> ON | OFF
PGENerator:PATTern:LED:BLUE <DutyCycle>
PGENerator:PATTern:LED:GREen <DutyCycle>
PGENerator:PATTern:LED:RED <DutyCycle>
Set the duty cycle of the red, green, and blue colors, which corresponds to the color
intensity.
Signal generation (option R&S
RTM-B6)
